TECHNICAL HIGHLIGHTS
-
One box solution, elegant and bold
-
No silicon
-
MC and MM inputs combined in one design
-
All 3 inputs RCA, also outputs fully balanced XLR's as well as SE RCA's
-
Tube dual diode rectified PSU
-
Pentode regulated PSU
-
Tube stages for input and output, circuits for MM and MC
-
No negative feedback
-
Premium parts
-
User switchable input loads for MC (low - mid-low , normal - mid high, high)
-
Finish Variants with black top, copper top, red paint top etc
Concealed tubes, Tube rolling possible -
Nixie display for 5 input loads and muting
-
Needle current meter
-
MUTE function
SPECIFICATIONS :
-
Inputs: One stereo MM input (RCA) and two stereo MC inputs (RCA)
-
Outputs: One stereo RCA output with < 1Kohm output impedance, one XLR stereo output with <1k per phase impedance
-
Amplification factor: Total of 3200x, (70 dB)
-
Cartridge compatibility: Moving Coil MC and Moving Magnet MM
-
Number of input load settings: 5 for MC, 1 for MM input
-
Output level on average music material: 2V pp
-
Output headroom: 10x
-
Power consumption: 60W
-
AC mains: 110/115/220/230V AC / 50 - 60Hz
-
Tube compliment: 4 x 6N2P-B, 4Xecc803, 2x 6N6P, 1x5881 or EL34, 1X6X5, 1 x Nixie
-
Shelf footprint: 43x51 cm (W x D)
-
Total height clearance: 13 cm
-
Weight (net / shipping gross): 17 kg / 25 kg (19/27 with copper)
-
Power supply: fully linear, 150 Watt, fully regulated for every consumption point.
-
Paid "visual" options: Copper top, spare kit of tubes.
- Warranty : 5 years (excluding tubes)
